Belt Conveyor

Belt conveyor mainly meet the aggregate use in different environments, the connection of the crushing and screening equipment and crushing and grinding equipment to achieve the continuity and automation of production process, improve productivity, reduce labor intensity.

Gallery Word PDF Bookmark Get Price

Kefid Gallery
Kefid Video
Mobile Crushing Plant
Crawler Mobile Crusher
Mobile Jaw Crusher
Mobile Impact Crusher
Mobile Cone Crusher
Mobile VSI Crusher
Stationary Crushing Plant
Jaw Crusher
Impact Crusher
Cone Crusher
VSI Crusher
Aggregate Production Line
Stone Crushing Plant
Sand Making Plant
Grinding Mill
Vertical Mill
MTW Series Trapezoid Mill
European Hammer Mill
Micro Powder Mill
Trapezium Mill
High Pressure Mill
Raymond Mill
Ball Mill
Screening & Washing
Vibrating Screen
Screw Sand Washing Machine
Wheel Sand Washing Machine
Feeding & Conveying
Vibrating feeder
Belt Conveyor

Contact Us (Shanghai)

Contact Us (Zhengzhou)

Please contact us online or send email to sales@kefidinc.com, if you want to find the nearest Belt Conveyor working site in your country.

Features of Belt Conveyor

The belt conveyor moves according to the abrasion and transmission principle, which can transport a great deal of materials, transport a long way, transport stably. And there is no relative movement between materials and the belt. It has advantages of low noise, simple structure, it’s easy to maintain and has low energy consumption and standardized parts.

Application of Belt Conveyor

Belt conveyor are widely used in the transportation equipment sector, such as the chemical industry, coal, metallurgy, mining, foundry, building materials, power, light, food, transportation, production lines and construction of hydropower stations and ports and other production sites. According to transportation technology requirements, the transfer system can be one or multi-conveyor or combined with other transfer equipments to meet the different layout of the operating line needs.

Belt conveyor can be operated in the circumstance temperature from -20℃ and to  40℃, the temperature of transferred material should be lower than 50℃. The conveyor length can be manufactured according to the needs of users.

Working Principle of Belt Conveyor

The belt conveyor is composed of frame, transferring belt, belt roller, intensive device, transmission device and so on. The machine body is made of high-quality steel plate joint. Frame is formed by height difference of front and back supporting legs, the category is a tilt with certain angle. On the frame, there are belt roller, carrier roller and so on for driving and supporting conveyor belt. There are two methods, driven by speed reducer and electric drum.

Get Free support and more discount!

Technical Data of Belt Conveyor

Belt Width(mm) Belt Length (m) / Power (kW) Belt Speed (m/s) Capacity (t/h)
500 ≤12/3 12-20/4-5.5 20-30/5.5-7.5 1.3-1.6 45-100
650 ≤12/4 12-20/5.5 20-30/7.5-11 1.3-1.6 70-120
800 ≤10/4 10-15/5.5 15-30/7.5-15 1.3-1.6 120-180
1000 ≤10/5.5 10-20/7.5-11 20-40/11-22 1.3-2.0 160-250
1200 ≤10/7.5 10-20/11 20-40/15-30 1.3-2.0 200-400

Note: Any change of Belt Conveyor technical data shall not be advised additionally.
